Tubular Glass Vial Small Glass Bottle 1ml
Size and Specifications of nuetral tubular glass vials: Raw material glass tubing of the neutral glass tubular glass via;
Basic Info.
| Model NO. | 1-30ml |
| Technics | Bottle Blowing |
| Glass Type | Nurtral Borosilicate Glass |
| Hydrolystic Property | USP Type I |
| Machine | Horizontal Machine |
| Transport Package | Cartons |
| Specification | 2ml |
| Trademark | SNAIL GLASS |
| Origin | China |
| HS Code | 70109090 |
| Production Capacity | 10000PCS/Year |
Product Description
Size and Specifications of nuetral tubular glass vials:
| Specification | ml | 2R | 4R | 6R | 8R | 10R | 15R | 20R | 25R | 30R | |
| Tube O.D. | d1 | mm | 16.00 | 22.00 | 24.00 | 30.00 | |||||
| Crown O.D. | d2 | mm | 13.00 | 20.00 | |||||||
| Max. Neck Diamter | d3 | mm | 10.50 | 16.00 | 16.50 | 17.50 | |||||
| Neck I.D. | d4 | mm | 7.00 | 12.60 | |||||||
| Overall L. | h1 | mm | 35.00 | 45.00 | 40.00 | 45.00 | 45.00 | 60.00 | 55.00 | 65.00 | 75.00 |
| Vial Top H. | h3 | mm | 8.00 | 8.50 | 9.00 | 10.00 | |||||
| Crown H. | h4 | mm | 3.60 | ||||||||
| Tube W.T. | s1 | mm | 1.00 | 1.20 | |||||||
| Min. Bottom Th. | s2 | mm | 0.70 | ||||||||
Raw material glass tubing of the neutral glass tubular glass vials:
| No | Physical & Chemical Pherformance | Data |
| 1 | Coefficient of mean liner expansion(20ºC;300ºC) | (5.0±0.5)*10-6/k |
| 2 | Transformation temperature | 560±15ºC |
| 3 | Softening point | 780±10ºC |
| 4 | Working point | 1150±20ºC |
| 5 | Density at 20ºC | 2.30±0.02g/m3 |
| 6 | Hydrolytic resistance(ISO 720) | HGA1 |
| 7 | Acid resistance(DIN 12116) | Class S1 |
| 8 | Alkali resistance(ISO 695) | Class A2 |
Production environment of the neutral borosilicate glass vials:
the products is produced in the certified plant, our plant has passed ISO 9001 and ISO15378.
Package and delivery of the nuetral borosilicate tubular glass vials
